144W PLC Street Light IP66
468,26 €
377,63 €
Laost otsas
SKU
B144A
144W LED Power Line Connection Compatible Street Light
<..."
| Lamp Rated Luminous Flux | 13 200 lm |
144W LED Power Line Connection Compatible Street Light
| Lamp Rated Luminous Flux | 13 200 lm |
| Color Temperature (CCT) | 4500 K (optional 3000K and 5700K) |
| Color Rendering Index (CRI) | Ra>75 |
| Lamp Rated Luminos Efficiency | 75 lm/W |
| Light Distribution Curve | Asymmetric (Bat Wing) / Rectangular |
| Beam Angle | 120°*60° ; 135°*65° ; 140°*75° |
| Size | 764 * 315 mm; height 86 mm |
| Suitable for Arm | 50-60 mm |
| Recommended Mounting Height | 8-12 m |
| LED qty. | 144 pcs. * 1W |
| LED Producer | Cree/Philips |
| LED modules | 6 |
| Remote control | Internet or GPRS |
| Input Voltage and frequency | ~100 - 240V; 47-63Hz |
| Lamp Body Material | Alumiiniumisulam ja plastmass |
| Ingress Protection Rate | IP65 (Optionally IP66) |
| Dimmable | 0-100% |
| Lights up | Immediately |
| Working Lifetime | >50000 hours |
| Number of Switching | Not Restricted |
| Lamp Rated Total Power | 176 W |
| Power Factor (PF) | 0,95 |
| Total Harmonic Distortion (THD) | < 15% |
| Working Temperature | -40°C - +50°C |
| Junction Temperature (Tj) | +60°C ± 10% at ambient +25°C |
| Relative Humidity | 10%-95% |
| Storage Temperature | -40°C - +80°C |
| CE ja RoHS | Yes |
| Net Weight | 14,0 kg |
High quality power supply, reliable and stable, automatically reduce current against overheating temperature.
Intelligent remote controlled and working status monitored by PLC and GPRS.
Equivalent to 400W high pressure sodium (HPS) lamp.
| SKU | B144A |
|---|---|
| Valmistatud | Hiina |
